TECHNOTHERM Wall Convector SPH Z DSM

Series Wall Convector SPH-Z 750 DSM with weekly/daily program, anthracite

The TECHNOTHERM SPH Z DSM wall convector is a direct heating convector with an aluminum heating element and integrated special ceramic storage for uniform, delayed heat release. The slim anthracite metal casing is only approximately 8 cm deep and is ideal for wall mounting. The side-mounted DSM thermostat electronically regulates room temperature with weekday programs, adaptive heating start, and open-window detection, and enables internet control via app. Two independent safety monitors reliably protect against overheating. Available in power levels from 750 W to 2.0 kW, ready for connection with a plug and Protection Class I.

High-quality technology – developed and manufactured in-house by TECHNOTHERM in Germany.

Safe and EU-compliant: Our systems meet all European safety and environmental requirements.

Tap icon/logo for more information

Pleasant stored heat

Special heat storage bricks store a portion of the heating energy and release it over an extended period. This ensures consistent temperatures and less cycling.

Slim on the wall, suitable for many rooms

The SPH devices have a depth of 8 cm, horizontal design strips, and power outputs from 750 to 2000 watts. This allows the wall convector to fit well under windows or on narrow wall surfaces.

Control suitable for the project

SPH plus with side-mounted control thermostat and up to nine programs directly on the device; SPH DSM with programmable digital thermostat, open-window function, and app connectivity; SPH RF with integrated radio receiver for TPF-ECO radio thermostat and TYDOM App. This provides a choice of simple, smart, or radio-controlled variants.

Rapid Direct Heat

The aluminum heating element generates instantly noticeable warmth – ideal for rooms requiring rapid heating.

Ceramic storage for delayed heat release

The integrated ceramic storage element stores heat and releases it with a time delay – for a longer-lasting heating effect.

Slim anthracite casing

The approximately 8 cm deep metal casing in modern anthracite allows for elegant, discreet wall mounting.

Smart DSM thermostat (side-mounted)

The side-mounted DSM thermostat offers programs, adaptive start function, and precise temperature control – comfortable and energy-efficient.

Internet Control via App or PC

Remote access and programming conveniently via smartphone or desktop – maximum control from anywhere.

Intelligent power adjustment

Automatic modulation of heating power, including open-window detection, ensures efficient, demand-oriented heating.

High safety

Two integrated overheating protection systems guarantee safe heating operation.

Power levels from 750 W to 2.0 kW

Flexible device selection from 0.75 to 2.0 kW, including plug connection (Protection Class I) – ready for immediate operation.

Technical Data

Model	Performance	Dimensions (W x H x D)	weight [approx.]	Order number	Inquire
TECHNOTHERM Wall Convector SPH Z 750 DSM	0.75 kW	750 x 500 x 90 mm	18.3 kg	429754770	Inquire now
TECHNOTHERM Wall Convector SPH Z 1000 DSM	1.0 kW	750 x 500 x 90 mm	18.3 kg	429754771	Inquire now
TECHNOTHERM Wall Convector SPH Z 1200 DSM	1.2 kW	750 x 500 x 90 mm	18.3 kg	429754772	Inquire now
TECHNOTHERM Wall Convector SPH Z 1500 DSM	1.5 kW	1050 x 500 x 90 mm	24 kg	429754773	Inquire now
TECHNOTHERM Wall Convector SPH Z 2000 DSM	2.0 kW	1050 x 500 x 90 mm	24 kg	429754774	Inquire now
TECHNOTHERM Wall Convector SPH Z H 1200 DSM	1.2 kW	500 x 1050 x 90 mm	18.3 kg	429754775	Inquire now
