TECHNOTHERM wall convector SPH RF Z

TECHNOTHERM wall convector SPH RF Z

Series Wall convector SPH-Z 750 with RF radio receiver, anthracite

The TECHNOTHERM SPH RF Z wall convector is a direct-heating convector with an aluminium heating element and an integrated special ceramic heat store for even, delayed heat release. The robust anthracite metal housing mounts slim to the wall at approx. 8 cm deep. A side pre-mounted RF radio receiver enables control via an external wireless room thermostat, e.g. TPF-Eco. Two independent safety monitors provide reliable overheat protection. Available in outputs from 750 W to 2.0 kW, ready to connect with plug and protection class I.

More Details
Inquire about Product
High-quality technology – developed and manufactured in-house by TECHNOTHERM in Germany.
Safe and EU-compliant: Our systems meet all European safety and environmental requirements.

Tap icon/logo for more information

Description
Features
Functions
Specifications
Downloads
Further Information

Comfortable stored heat

Special heat storage stones store part of the heating energy and release it over a longer period. This ensures even temperatures and less cycling.

Slim on the wall, fits many rooms

The SPH units are 8 cm deep, feature horizontal design lines, and offer outputs from 750 to 2000 W. This makes the wall convector a good fit under windows or on narrow wall areas.

Control to suit the project

SPH plus with side control thermostat and up to nine programs directly on the unit, SPH DSM with programmable digital thermostat, open-window function and app connectivity, SPH RF with integrated radio receiver for the TPF-ECO wireless thermostat and TYDOM app. This gives you a choice of simple, smart or radio-controlled variants.

Rapid Direct Heat

The aluminium heating element delivers instantly noticeable warmth—ideal for rooms that need to heat up quickly.

Ceramic heat store for delayed heat release

The integrated ceramic heat store retains heat and releases it with a delay—for longer-lasting heating performance.

Slim anthracite housing

The approx. 8 cm deep metal housing in modern anthracite blends discreetly into the room and is ideal for wall mounting.

Integrated RF radio receiver (side-mounted)

Side-integrated RF radio receiver for control via an external thermostat—enables flexible, wireless temperature control.

Intelligent power adjustment

Automatic modulation of heating output, including programs and open-window detection, ensures energy-efficient, demand-based operation.

High safety

Two integrated overheat protection systems ensure safe and reliable heating operation.

Power levels from 750 W to 2.0 kW

Wide output range from 0.75 to 2.0 kW, including plug connection (protection class I)—ready to use right away.

Technical Data

ModelPerformanceDimensions (W x H x D)weight [approx.]Order numberInquire
TECHNOTHERM wall convector SPH 750 RF Z0.75 kW750 x 500 x 90 mm18.3 kg429754780Inquire now
TECHNOTHERM wall convector SPH 1000 RF Z1.0 kW750 x 500 x 90 mm18.3 kg429754781Inquire now
TECHNOTHERM wall convector SPH 1200 RF Z1.2 kW750 x 500 x 90 mm18.3 kg429754782Inquire now
TECHNOTHERM wall convector SPH 1500 RF Z1.5 kW1050 x 500 x 90 mm24 kg429754783Inquire now
TECHNOTHERM wall convector SPH 2000 RF Z2.0 kW1050 x 500 x 90 mm24 kg429754784Inquire now
TECHNOTHERM wall convector SPH H 1200 RF Z1.2 kW500 x 1050 x 90 mm18.3 kg429754785Inquire now
